说明：
上面的橙色单元格是grid-column:1/6;grid-row:1/2;
左边的蓝色单元格grid-column:1/3;grid-row:2/4;
正确的绿色单元格是grid-column:3/6;grid-row:2/3;
左下方的灰色单元格是grid-column:1/3;grid-row:4/5;
右下方的黄色单元格是grid-column:3/6;grid-row:3/5;
下面的白色单元格是
grid-column:1/2;grid-row:5/6;
grid-column:2/3;grid-row:5/6;
grid-column:3/4;grid-row:5/6;
grid-column:4/5;grid-row:5/6;
grid-column:5/6;grid-row:5/6;
下面将上述布局写入网格单元格的类中。
代码如下
编写以下HTML，CSS。
SimpleGrid.html
<!DOCTYPEhtml><html><head>
<metacharset="utf-8"/>
<linkrel="stylesheet"href="GridMerge.css"/>
<title></title>
</head>
<body>
<divclass="Container">
<divclass="GridItem1">内容1</div>
<divclass="GridItem2">内容2</div>
<divclass="GridItem3">内容3</div>
<divclass="GridItem4">内容4</div>
<divclass="GridItem5">内容5</div>
<divclass="GridItem6">内容6</div>
<divclass="GridItem7">内容7</div>
<divclass="GridItem8">内容8</div>
<divclass="GridItem9">内容9</div>
<divclass="GridItem10">内容10</div>
</div>
</body>
</html>
SimpleGrid.css
.Container{
display:grid;
grid-template-columns:160px160px160px160px160px;
grid-template-rows:120px120px120px120px120px;
border:solid#ff6a001px;
}
.GridItem1{
grid-column:1/6;
grid-row:1/2;
background-color:#ff9c9c;
}
.GridItem2{
grid-column:1/3;
grid-row:2/4;
background-color:#ffcb70;
}
.GridItem3{
grid-column:1/3;
grid-row:4/5;
background-color:#7ee68d;
}
.GridItem4{
grid-column:3/6;
grid-row:2/3;
background-color:#7ee6e2;
}
.GridItem5{
grid-column:3/6;
grid-row:3/5;
background-color:#95a7f5;
}
.GridItem6{
grid-column:1/2;
grid-row:5/6;
background-color:#d095f5;
}
.GridItem7{
grid-column:2/3;
grid-row:5/6;
background-color:#e1bbfa;
}
.GridItem8{
grid-column:3/4;
grid-row:5/6;
background-color:#d2b1e4;
}
.GridItem9{
grid-column:4/5;
grid-row:5/6;
background-color:#dcd2e1;
}
.GridItem10{
grid-column:5/6;
grid-row:5/6;
background-color:#eee8f1;
}
